Killer Quad 27.5”

€1.099,00
Description

Now this is one KILLER ride! The all-new 27.5” Killer Quad is perfection on wheels. This bike has everything you’d want and more. It is built around a unique Quad frame design featuring an oversized downtube, integrated headset, super stiff BB yoke, and a legendary looptail rear end. It comes equipped with a microSHIFT XLE 1x10 drivetrain, Tektro hydraulic disc brakes, and wide 27.5” x 2.5” Vee Speedster tires. When you want to go for a killer ride, this is definitely the bike to have.

Color
KEY FEATURES
  • 6061 Aluminum Killer Quad frame with oversized downtube, integrated headset, and looptail rear end
  • Full Cr-Mo Landing Gear forks |SE Racing forged alloy 2-piece cranks with 24mm hollow alloy spindle, external sealed bearing bottom bracket, and alloy chainring
  • FSA Orbit CE integrated sealed bearing headset
  • Vee Tire Co x SE Racing 72tpi Speedster 27.5" x 2.5" tires
  • MicroShift XLE RD-M61S 1x10 short-cage derailleur
  • Sealed-bearing rear alloy hub with double-wall rims and microSHIFT 11-32T 10-speed cassette
  • Tektro hydraulic disc brakes with easy to adjust open system, dual piston, 160mm rear rotor, 180mm front rotor
  • SE Flyer seat with bottle opener
  • 33.9 pounds
SPECIFICATIONS
Suggested Rider Size5'3"+ (160cm+)
Color(s)High Polish Silver
Frame6061 Aluminum, Single Downtube Killer Quad Design, Internally-machined Integrated Head Tube, Looptail Rear End, Fixed Dropouts, 73mm Euro Bottom Bracket, 135mm Spaced Dropouts, Disc Brake Tabs, Removable Derailleur Hanger
ForkLanding Gear, Full Cr-Mo, 419mm Axle to Crown, 29mm Offset, 110mm Spaced Dropouts
CranksetSE Racing 175mm Forged Alloy 2-pc Cranks, External Sealed Euro Bottom Bracket, 24mm Hollow Alloy Spindle, 32T Alloy Chainring
PedalsWellgo Low-profile Platform
Rear DerailleurMicroShift XLE RD-M61S, 1x10, Short Cage
ShiftersMicroShift XLE Xpress SL-M850-R, 1x10, Sealed Bearing, Alloy Lever
CassetteMicroShift XLE CS-H100, 10-speed, 11-32T
ChainKMC S1
WheelsetAlloy 36H Nutted Hubs, 135mm Sealed Rear Hub, 110mm Front Hub, Double-wall Rims, 11-32T 10-speed Cassette, Stainless Spokes
TiresVee Tire Co x SE Racing Speedster, 72TPI, 27.5" x 2.5" Front & Rear
BrakesetTektro HD-M285, Hydraulic Disc, Easy to Adjust Open System, Dual Piston, Automatic Caliper Positioning, 180mm Front Rotor, 160mm Rear Rotor
Brake LeversTektro HD-M285, 2-Finger Alloy, Front & Rear
HeadsetFSA Integrated Orbit CE, Sealed 1-1/8"
HandlebarBig Honkin' Cr-Mo Cruiser Bar, 31" x 7", 12° Backsweep, 2° Upsweep
StemRetro Alloy Top-Load w/ Engraved SE Logo on Top & Sides, 55mm Reach
GripsSE Racing Flangeless Mushroom Wing Grips w/ SE Rubber End Plugs
SeatSE Flyer Seat w/ Custom SE Bottle Opener Brace
SeatpostMicro-Adjust Alloy, 27.2mm
Seat ClampSE Racing Champ Clamp, Alloy, 31.8mm Inner Diameter
AccessoriesAlloy Valve Caps, Removable Derailleur Hanger
Weight33.9 lbs / 15.39 kgs
GEOMETRY
ATop Tube, Actual 22.8"
BSeat Tube, Center To Top15.7"
CSeat Tube Angle 73°
DHead Tube Angle 71°
EChainstay Length17.4"
FWheelbase42.3"
GBottom Bracket Height 11.9"
HStandover28.2"
Stem55mm
Handlebar Width31"
Crank175mm
Wheel Size27.5"
Seat Post Diameter27.2mm
